V Type Disc Harrow (CVD)


Loading Products...

CVD-V Type Towed Disc Disc Harrow" is used for processes such as cutting the plow by completing the work of the plow, preparing the seed bed by mixing the soil, cutting and shredding the plant waste and weeds in the field, mixing the fertilizer into the soil. It is also produced in disc diameter (460 mm-510 mm-560 mm).



TECHNICAL SPECIFICATIONS

 Model   Disc Number   Disc Diameter (mm)   Disc Spacing (mm)   Working Width (mm)   Weight (kg)   Required Power (hp)
 CVD 24  24  460  172  2000  625  60 - 70
 CVD 28  28  460  172  2350  700  70 - 80
 CVD 32   32  460  172  2700  730  80 - 90
 CVD 36     36  460  172  3050  850  90 - 100
 CVD 40  40  460  172  3400  940  100 - 110
 CVD 44  44  460  172  3750  1020  110 - 120
